Low-profile, off-center loading load cell. Designed for direct mounting of a weighing platform, hanging scales and other low-capacity beam applications. Stainless steel construction with a humidity-resistant protective coating provides long-term stability, even in harsh environments. Potted cavities provide improved performance in damp environments. Capacities range from 10 kg to 200 kg. Complete with 10 ft of load cell cable.
| Rated Capacity | H | H1 | L | L1 | L2 | L3 | L4 | L6 | W | T | T2 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| kg/mm | |||||||||||
| 10 to 100 | 40.0 | 10.0 | 150.0 | 100.0 | 19.0 | 32.0 | 6.0 | 20.0 | 25.4 | 1/4-20 UNC × 19.1 DP | N/A |
| 200 | 40.0 | 10.0 | 150.0 | 100.0 | 19.0 | 32.0 | 6.0 | 20.0 | 38.1 | 1/4-20 UNC × 19.1 DP | 25.4 |
| Full Scale Output: 2.0 mV/V Output Resistance: Input Resistance: Material/Finish: Temperature: Seal Type: |
Safe Overload: 200% full scale Rated Excitation: Combined Error: Insulation Resistance: Cable Length: Cable Diameter: |
Max Platform Size: 18 × 18 in Cable Color Code: Warranty: Approvals: |
