Full Scale Output:
2.0mV/V
Output Resistance:
359 (± 10) ohm
Input Resistance:
390 (± 15) ohm
Material/Finish:
Stainless steel
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C) |
Seal Type:
Environmentally sealed, IP67
Safe Overload:
150% full scale
Rated Excitation:
5 to 10 VDC (15 V maximum)
Combined Error:
0.03% full scale
Insulation Resistance:
5,000 megohm
Cable Length:
10 ft
Cable Diameter:
0.190 in polyurethane jacket |
Deflection:
<0.4 mm full scale
Max Platform Size:
15.75 × 15.75 in
Cable Color Code:
Green +Excitation
Black –Excitation
White +Signal
Red –Signal
Yellow Shield
Warranty:
Two-year limited
Approvals:
FM
NTEP 94-128 |
