A single-point cell, constructed of stainless steel and designed for performance in harsh, high-shock load environments. Ideal for platform scales as well as packaging and process weighing equipment. Capacities range from 7 kg to 150 kg. Complete with 10 ft of load cell cable.
| Rated Capacity | A | B | C | D | E | F | G |
|---|---|---|---|---|---|---|---|
| kg/mm | |||||||
| 7 to 15 | 30.2 | 139.7 | 19.1 | 6.4 | 88.9 | 1/4-20 UNC | 19.1 |
| 30 to 60 | 30.2 | 139.7 | 19.1 | 6.4 | 88.9 | 1/4-20 UNC | 23.9 |
| 100 to 150 | 30.2 | 139.7 | 22.3 | 7.8 | 79.2 | 3/8-16 UNC | 30.7 |
| Full Scale Output: 2.0 mV/V Output Resistance: Input Resistance: Material/Finish: Temperature: |
Seal Type: Environmentally sealed, IP67 Safe Overload: Rated Excitation: Combined Error: Insulation Resistance: Cable Length: Cable Diameter: |
Deflection: <0 .4 mm full scale Cable Color Code: Warranty: Approvals: |
