Full Scale Output:
3.0 mV/V
Output Resistance:
349 to 355 ohm
Input Resistance:
343 to 357 ohm
Material/Finish:
High-alloy steel, nickel plated
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Seal Type:
Environmentally sealed, IP67 |
Safe Overload:
150% full scale
Safe Sideload:
100% full scale
Rated Excitation:
5 to 10 V DC (15 V DC max)
Combined Error:
0.02% full scale
Insulation Resistance:
5,000 megohm
Deflection at Capacity:
1,000 lb: 0.013 in
2,500 lb: 0.015 in |
Cable Length:
10 ft
Cable Diameter:
0.200 in
Polyurethane jacket
Cable Color Code:
Red +Excitation
Black –Excitation
Green +Signal
White –Signal
Warranty:
One-year limited
Approvals:
cFMus
NTEP |
