Description
Switch type
Dry contact snap-action, Contact type: 1 SPDT, Contact behavior: Bistable (magnetically latched), Switching capacity (non-inductive loads): 230V AC, 200VA, 5A or 230V DC, 60W, 2A
Housing Options
NEMA 4X Epoxy coated aluminum, XP/I/1BCDT6 aluminum or stainless or NEMA 7/9 FM class 1, division 1, group B
Electrical Approvals
FM
Hysteresis
5-10 mm
Termination Type
Terminal block
