Full Scale Output:
2.0 mV/V
Output Resistance:
1,025 (± 20) ohm
Input Resistance:
1,065 (± 60) ohm
Material/Finish:
Stainless steel
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Seal Type:
Hermetically sealed, IP68 |
Safe Overload:
150% at center loading point, full scale
Rated Excitation:
5 to 10 VDC (15 V maximum)
Combined Error:
0.020% full scale
Insulation Resistance:
2,000 megohm
Deflection at Capacity:
< 0.5 mm at full scale
Cable Length:
5,000 kg: 5 m
10,000 to 20,000 kg: 10 m
30,000 kg: 20 m |
Cable Diameter:
0.220 in
Polyurethane jacket
Cable Color Code:
Blue +Excitation
Black –Excitation
White +Signal
Red –Signal
Green +Sense
Gray –Sense
Warranty:
One-year limited
Approvals:
cFMus
OIML
NTEP |
