A lower profile single point load cell for platform weighing. This model is constructed of aluminum and is a two-beam design. This design offers high immunity to side forces and is specially coated to provide humidity resistance. Capacities range from 1 to 100 kg. Complete with 10 ft of load cell cable.
| Rated Capacity | A | H | L | L1 | L2 | L3 | L4 | L5 | L6 | W | W1 | T |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| kg/mm | ||||||||||||
| 1 to 30 | 20.0 | 39.0 | 150.0 | 19.0 | 100.0 | 25.0 | 34.0 | 19.0 | 34.0 | 40.0 | 1.0 | 1/4-20 UNC |
| 50 to 100 | 25.2 | 39.0 | 150.0 | 19.0 | 100.0 | 25.0 | 34.0 | 19.0 | 34.0 | 40.0 | 1.0 | 1/4-20 UNC |
| Full Scale Output: 2.0 mV/V Output Resistance: Input Resistance: Material/Finish: Temperature: Seal Type: |
Safe Overload: 150% full scale Rated Excitation: Combined Error: Deflection at Capacity: Insulation Resistance: Cable Length: Cable Diameter: |
Platform Size: 16 × 16 in Cable Color Code: Warranty: Approvals: |
