Full Scale Output:
2.0 mV/V
Output Resistance:
350 (± 10) ohm
Input Resistance:
380 (± 15) ohm
Material/Finish:
Stainless steel
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Seal Type:
Hermetically sealed, IP69K |
Safe Overload:
150% full scale
Rated Excitation:
5 to 10 VDC (15 V maximum)
Combined Error:
0.02% full scale
Insulation Resistance:
1,000 megohm
Cable Length:
10 ft
2.83 ft
Cable Diameter:
0.212 in
PVC jacket |
Platform Size:
500 × 400 mm
Cable Color Code:
Blue +Excitation
Black –Excitation
White +Signal
Red –Signal
Green +Sense
Grey –Sense
Warranty:
Two-year limited
Approvals:
FM
NTEP 09-015 |
