Full Scale Output:
2.0 mV/V
Bridge Resistance:
350 ohm, nominal
Material/Finish:
Stainless steel
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Seal Type:
Environmentally sealed, IP67 |
Safe Overload:
150% full scale
Rated Excitation:
5 to 10 VDC (15 V maximum)
Combined Error:
0.02% full scale
Insulation Resistance:
1,000 megohm
Cable Length:
10 ft
Cable Diameter:
0.190 in
PVC jacket |
Max Platform Size:
15 × 15 in
Cable Color Code:
Blue +Excitation
Black –Excitation
White +Signal
Red –Signal
Green +Sense
Grey –Sense
Warranty:
Two-year limited
Approvals:
FM
NTEP 11-038 |
