Full Scale Output:
1.8 mV/v nominal
Output Resistance:
1,000 (± 10) ohm
Input Resistance:
1,000 ohm
Material/Finish:
Stainless steel
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C) |
Seal Type:
Welded-seal, IP67
Safe Overload:
150% full scale
Rated Excitation:
5 to 10 VDC
Combined Error:
0.025% full scale
Non-repeatability:
0.01% full scale
Insulation Resistance:
1,000 megohm |
Cable Length:
30 ft
Cable Diameter:
0.200 in overbraid cable
Cable Color Code:
Green +Excitation
Black –Excitation
White +Signal
Red –Signal
Warranty:
Two-year limited
Approvals:
NTEP 06-022
cFMus |
