This stainless steel load cell is the metric version of the RL32018S. Sealed to IP67 standards, load cell capacities range from 300 to 5000 kg. OIML approved and comes with 20 ft of cable.
| Rated Capacity | A | B | C | D | E | F | G | H | I | J | K | L | M | N |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| kg/mm | ||||||||||||||
| 300 to 2,000 | 31.5 | 15.0 | 34.6 | 56.0 | 31.5 | 130.0 | 13.5 | 18.0 | M12 | 76.2 | 25.4 | 15.8 | 6.5 | 3.5 |
| 3,000 to 5,000 | 48.0 | – | 37.0 | 76.0 | 41.5 | 171.5 | 20.5 | 18.0 | – | 75.2 | 38.1 | 19.0 | – | – |
| Full Scale Output: 2.0 mV/V ±0.05% current matchedOutput Resistance: 350 (± 3) ohm Input Resistance: Material/Finish: Temperature: |
Seal Type: Hermetically sealed, IP69KSafe Overload: 150% full scale Safe Sideload: Rated Excitation: Combined Error: Insulation Resistance: |
Deflection: 0.2 to 0.4 mmCable Length: 5 m Cable Color Code: Warranty: Approvals: |
