The perfect selection for new or retrofit scales with compact size, high accuracy and low cost. Stainless steel construction with a humidity-resistant protective coating helps ensure stable operation in damp environments. NTEP Certified and available with OIML approval. It comes with 10 ft of standard load cell cable. Capacities range from 10 kg to 150 kg.
| Rated Capacity | A | B | C | D | E | F | G | H | T | T1 |
|---|---|---|---|---|---|---|---|---|---|---|
| kg/mm | ||||||||||
| 10 to 150 kg | 150.0 | 19.1 | 39.0 | 34.0 | 125.0 | 115.0 | 40.00 | 25.4 | 1/4-20 UNC | 1/4-28 UNF |
| Full Scale Output: 2.0 mV/V Output Resistance: Input Resistance: Material/Finish: Temperature: Seal Type: |
Safe Overload: 150% full scale Rated Excitation: Combined Error: Deflection at Capacity: Insulation Resistance: Cable Length: Cable Diameter: |
Platform Size: 16 × 16 in Cable Color Code: Warranty: Approvals: |
