Full Scale Output:
2.0 ± 0.1% mV/V
Output Resistance:
699 to 707 ohm
Input Resistance:
686 to 714 ohm
Material/Finish:
Stainless steel
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F(-18 °C to 65 °C)
Seal Type:
Welded-seal, IP67 |
Safe Overload:
150% full scale
Safe Sideload:
100% full scale
Rated Excitation:
5 to 10 VDC (15 V maximum)
Non-repeatability:
0.01% full scale
Combined Error:
0.03% full scale
Insulation Resistance:
5,000 megohm
Deflection at Capacity:
0.01 in |
Cable Length:
35 ft
Cable Diameter:
0.305 in
Polyurethane jacket
Cable Color Code:
Red +Excitation
Black –Excitation
White +Signal
Green –Signal
Warranty:
Two-year limited
Approvals:
cFMus
NTEP 92-018 |
