Full Scale Output:
2.0 (± 0.1%) mV/V
Output Resistance:
350 (± 3) ohm
Input Resistance:
385 (± 10) ohm
Material/Finish:
Stainless steel
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Seal Type:
Environmentally sealed, IP67 |
Safe Overload:
150% full scale
Safe Sideload:
100% full scale
Rated Excitation:
5 to 10 VDC
Combined Error:
0.02% full scale
Non-Repeatability:
± 0.01% full scale
Insulation Resistance:
5,000 megaohm |
Cable Length:
20 ft
Cable Diameter:
0.190 in polyurethane jacket
Cable Color Code:
Green +Excitation
Black –Excitation
White +Signal
Red –Signal
Warranty:
Two-year limited
Approvals:
NTEP 11-024 |
