Full Scale Output:
3.0 mV/V
Bridge Resistance:
350 ohm, nominal
Material/Finish:
High-alloy steel, nickel plated
Temperature:
Compensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Seal Type:
Environmentally sealed, IP67
Safe Overload:
150% full scale |
Safe Sideload:
100% full scale
Rated Excitation:
5 to 10 VDC (15 V maximum)
Combined Error:
0.02% full scale
Insulation Resistance:
5,000 megohm
Deflection at Capacity:
1,000 lb: 0.013 in
2,000 to 3,000 lb: 0.015 in
4,000 to 5,000 lb: 0.025 in
Cable Length:
20 ft |
Cable Diameter:
0.200 in polyurethane jacket
Cable Color Code:
Red +Excitation
Black –Excitation
Green +Signal
White –Signal
Warranty:
Two-year limited
Approvals:
cFMus
NTEP 98-043 |
